器材规格
Form Integrated stereo amplifier
Rated continuation average output
(Both channel operation, 20Hz - 20kHz) 115 W/ch (4ohms)
105 W/ch (6ohms)
90 W/ch (8ohms)
THD (both channel operation) 0.04% (4ohms - 16-ohm load)
IM distortion 0.01%
Frequency response High Level input: 20Hz-20kHz+0 -0.2 dB (at the time of a rated continuation average output)
Dumping factor 100 (8-ohm load, 50Hz)
Input sensitivity/impedance
(An Output power / EIA1W output) High Level input: 213mV/22.5mV/20kohm
Balanced input: 213mV/22.5mV/40kohm
Gain High Level input -> output: 42dB
S/N, input conversion noise
Input short-circuit and A-compensation EIA S/N
At the time of an Output power S/N Input conversion noise
High Level input: 110dB -129dBV 81dB
Balanced input: 92dB -111dBV 81dB
Tone control Low-pitched sound (300Hz): ±10dB (50Hz)
Loud sound (3kHz): ±10dB (20kHz)
Loudness Compensation + 6dB (200Hz, Volume-30dB)
Power meter Logarithm compression type peak level display
dB scale and the output Direct reading at the time of 8-ohm load
Load impedance 4ohm-16ohm
Headphone jack Conformity impedance: 8ohms - 100ohms
Power source AC100V, 50Hz/60Hz
Power consumption 30W (at the time of no inputting)
220W (Electrical Appliance and Material Control Law)
336W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 150x depth of 422mm
Weight 18.9kg
Attachment Remote commander RC-23
AC power cord
Rated continuation average output
(Both channel operation, 20Hz - 20kHz) 115 W/ch (4ohms)
105 W/ch (6ohms)
90 W/ch (8ohms)
THD (both channel operation) 0.04% (4ohms - 16-ohm load)
IM distortion 0.01%
Frequency response High Level input: 20Hz-20kHz+0 -0.2 dB (at the time of a rated continuation average output)
Dumping factor 100 (8-ohm load, 50Hz)
Input sensitivity/impedance
(An Output power / EIA1W output) High Level input: 213mV/22.5mV/20kohm
Balanced input: 213mV/22.5mV/40kohm
Gain High Level input -> output: 42dB
S/N, input conversion noise
Input short-circuit and A-compensation EIA S/N
At the time of an Output power S/N Input conversion noise
High Level input: 110dB -129dBV 81dB
Balanced input: 92dB -111dBV 81dB
Tone control Low-pitched sound (300Hz): ±10dB (50Hz)
Loud sound (3kHz): ±10dB (20kHz)
Loudness Compensation + 6dB (200Hz, Volume-30dB)
Power meter Logarithm compression type peak level display
dB scale and the output Direct reading at the time of 8-ohm load
Load impedance 4ohm-16ohm
Headphone jack Conformity impedance: 8ohms - 100ohms
Power source AC100V, 50Hz/60Hz
Power consumption 30W (at the time of no inputting)
220W (Electrical Appliance and Material Control Law)
336W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 150x depth of 422mm
Weight 18.9kg
Attachment Remote commander RC-23
AC power cord
