器材规格
Form Stereo power amplifier
Continuation average output
(20Hz - 20kHz) At the time of stereo specification (both channel simultaneous operation)
400 W/ch: 2-ohm load
300 W/ch: 4-ohm load
200 W/ch: 8-ohm load
100 W/ch: 16-ohm load
At the time of monophonic specification (bridge connection)
800W:4-ohm load
600W:8-ohm load
400W:16-ohm load
THD At the time of stereo specification (both channel simultaneous operation)
2ohms - 0.02% and 16-ohm load
At the time of monophonic specification (bridge connection)
4ohms - 0.02% and 16-ohm load
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a continuation average output level control MAX)
0.5Hz-16k0Hz+0 -3.0 dB (at the time of 1W output a level control MAX --6dB)
Gain (profit) 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 2ohms - 16ohms
At the time of monophonic specification (bridge connection): 4ohms - 16ohms
Dumping factor At the time of stereo specification: 300
At the time of monophonic specification (bridge connection): 150
Input sensitivity (8-ohm load) At the time of stereo specification
1.59V: At the time of a continuation average output
0.11V: At the time of 1W output
At the time of monophonic specification (bridge connection)
2.76V: At the time of a continuation average output
0.11V: At the time of 1W output
Input impedance Balance: 40kohm
Unbalance: 20kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a continuation average output)
100dB (at the time of input 1kohm and 1W output)
Stereo headphone Conformity impedance: 4ohms - 1000ohms
Power output meter A logarithm compression type, -50dB-+3dB, and an output Direct-reading scale
The semiconductor used Transistor: 63 pieces
FET: 32 pieces
IC: Ten pieces
Diode: 77 pieces
Power source 100V, 117V, 220V, 240V, 50Hz/60Hz
Power consumption At the time of no inputting: 100W
Electrical Appliance and Material Control Law: 590W
At the time of an 8ohm Output power: 633W
Dimensions the width 475x height 180(piece -- it includeds) x depth of 409mm
Weight 27.4kg
Continuation average output
(20Hz - 20kHz) At the time of stereo specification (both channel simultaneous operation)
400 W/ch: 2-ohm load
300 W/ch: 4-ohm load
200 W/ch: 8-ohm load
100 W/ch: 16-ohm load
At the time of monophonic specification (bridge connection)
800W:4-ohm load
600W:8-ohm load
400W:16-ohm load
THD At the time of stereo specification (both channel simultaneous operation)
2ohms - 0.02% and 16-ohm load
At the time of monophonic specification (bridge connection)
4ohms - 0.02% and 16-ohm load
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a continuation average output level control MAX)
0.5Hz-16k0Hz+0 -3.0 dB (at the time of 1W output a level control MAX --6dB)
Gain (profit) 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 2ohms - 16ohms
At the time of monophonic specification (bridge connection): 4ohms - 16ohms
Dumping factor At the time of stereo specification: 300
At the time of monophonic specification (bridge connection): 150
Input sensitivity (8-ohm load) At the time of stereo specification
1.59V: At the time of a continuation average output
0.11V: At the time of 1W output
At the time of monophonic specification (bridge connection)
2.76V: At the time of a continuation average output
0.11V: At the time of 1W output
Input impedance Balance: 40kohm
Unbalance: 20kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a continuation average output)
100dB (at the time of input 1kohm and 1W output)
Stereo headphone Conformity impedance: 4ohms - 1000ohms
Power output meter A logarithm compression type, -50dB-+3dB, and an output Direct-reading scale
The semiconductor used Transistor: 63 pieces
FET: 32 pieces
IC: Ten pieces
Diode: 77 pieces
Power source 100V, 117V, 220V, 240V, 50Hz/60Hz
Power consumption At the time of no inputting: 100W
Electrical Appliance and Material Control Law: 590W
At the time of an 8ohm Output power: 633W
Dimensions the width 475x height 180(piece -- it includeds) x depth of 409mm
Weight 27.4kg
