器材规格
Form Control amplifier
Output load impedance Balance: 500ohms
Unbalance: 250ohms
Input sensitivity/impedance Line: 900mV / 50kohm (balance)
450mV / 22kohm (unbalance)
Phone (man-month): 4.5mV / 47kohm
Gain A line -> pre out: 15dB
Line -> tapes output: 0dB
Phone man month -> pre out: 55dB
Phone man-month-> tapes output: 40dB
THD 0.002% or less
Input terminal Line (RCA): Eight lines (one inner phone man month/Aux switchover)
Line (XLR): Two lines
6chRCA: Two lines
Sound-recording output-terminal RCA: Two lines
Pre-out termination 6chRCA: One line (one inner 2ch combination output)
2chRCA: One line
6chXLR: One line (one inner 2ch combination output)
2chXLR: One line
Power consumption 35W
The maximum Dimensions Width 445x height 152x depth of 405mm
Weight 9.5kg
Adjunct Remote control
Output load impedance Balance: 500ohms
Unbalance: 250ohms
Input sensitivity/impedance Line: 900mV / 50kohm (balance)
450mV / 22kohm (unbalance)
Phone (man-month): 4.5mV / 47kohm
Gain A line -> pre out: 15dB
Line -> tapes output: 0dB
Phone man month -> pre out: 55dB
Phone man-month-> tapes output: 40dB
THD 0.002% or less
Input terminal Line (RCA): Eight lines (one inner phone man month/Aux switchover)
Line (XLR): Two lines
6chRCA: Two lines
Sound-recording output-terminal RCA: Two lines
Pre-out termination 6chRCA: One line (one inner 2ch combination output)
2chRCA: One line
6chXLR: One line (one inner 2ch combination output)
2chXLR: One line
Power consumption 35W
The maximum Dimensions Width 445x height 152x depth of 405mm
Weight 9.5kg
Adjunct Remote control
