器材规格
Form Control amplifier
Input sensitivity/impedance Tuner: 150mV/50kohm
compact-disk: 150mV/50kohm
Line1-4:150mV/50kohm
An Output voltage/impedance Coaxial: Rate 1V/300 ohm, a maximum of 7.5v
Balance: Rate 1V/600 ohm, a maximum of 7.5v
THD 0.005% or less (rate)
Frequency characteristic 20Hz - 20000Hz, and +0 -0.1 dB
S/N ratio 120dB or more
Tone control Treble: Turnover 3kHz A maximum of ±8dB (10kHz±6dB)
Bass: Turnover 300Hz A maximum of ±8dB (100kHz±6dB)
An attached functionality Tapes dubbing: Two lines (1->2, 2->1)
REC OFF
Straight switchpoint
Output mode changeover switch
Remote (Power) output
Line phase sensor
Output phase changeover switch
Supply voltage AC100V, 50Hz/60Hz
Power consumption 38W (convention by Electrical Appliance and Material Control Law)
Dimensions Width 467x height 187x depth of 475mm
Weight 23.0kg
Input sensitivity/impedance Tuner: 150mV/50kohm
compact-disk: 150mV/50kohm
Line1-4:150mV/50kohm
An Output voltage/impedance Coaxial: Rate 1V/300 ohm, a maximum of 7.5v
Balance: Rate 1V/600 ohm, a maximum of 7.5v
THD 0.005% or less (rate)
Frequency characteristic 20Hz - 20000Hz, and +0 -0.1 dB
S/N ratio 120dB or more
Tone control Treble: Turnover 3kHz A maximum of ±8dB (10kHz±6dB)
Bass: Turnover 300Hz A maximum of ±8dB (100kHz±6dB)
An attached functionality Tapes dubbing: Two lines (1->2, 2->1)
REC OFF
Straight switchpoint
Output mode changeover switch
Remote (Power) output
Line phase sensor
Output phase changeover switch
Supply voltage AC100V, 50Hz/60Hz
Power consumption 38W (convention by Electrical Appliance and Material Control Law)
Dimensions Width 467x height 187x depth of 475mm
Weight 23.0kg
